Clearance test
Base 20mm each step adds 0.2 mm clearance. top 19.4mm.
ring ID is 20mm, ring wall is 1.2mm for 3 wall 0.4mm layer width
2
23
0
238
updated April 11, 2023
Description
PDFring width (1.2mm) is for flow calibration with 3 walls .4mm
Rind ID is 20mm for hole compansation after flow tune if necessary
tower bottom is for horizontal expansion after flow calibration if necessary
each step on tower going up decreases didth by 0.2mm for easy dimentional accuracy tuning.
for this to work as intended your seam setting and or coasting gotta be tuned and produce seams withoult exess material bulging
