Anycubic 4Max Pro E3D Titan V6 Mod

NOTE: This is still beta - it already fully usable but still needs a little more polishing

This mod allows you to use anE3D Titan Extruder includingE3D V6 or Volcano Hotend on your Anycubic 4Max Pro.

It is non-destructive, so you can switch back to the original extruder if necessary. You need some M3 screws - which you can take from the original extruder and the screws of the Titan Extruder

Print the main part and two standoffs. Part-cooler and deflector for the hotend-cooler are also attached

It's possible to use the original Anycubic Stepper Motor for this. I also will upload a add-on for the slim line motor.

E steps have to be adjusted in Firmware to 837 Steps-per-mm (see E3D Titan documentation)

The nozzle is about 7mm closer to the heatbed, so you have to pay attention to your z-axis endstop - otherwise the nozzle will run into the bed. I solved this by glueing a 7mm hexnut to the place where the z-endstop-switch touches.

Printed with PLA or PETG and 0,15 to 0,2mm layer height - also about 15-20% infill
