Fixture for HP Thunderbolt 4 Dock

Fixture for HP Thunderbolt 4 Dock on movable surfaces
1
21
0
503
updated March 26, 2023

Description

PDF

I'm using a HP Thunderbolt 4 Dockingstation in a kind of drawer. To hold the docking statin in place while moving the drawer I have created this model.

I have very limited space above, therefore the base is very thin (0,4mm).

Additionally, I added to fixtures for the cable.

The fixture can be glued with double sided tape.

I used PLA with 0,1mm layers (PrusaSlicer 0,1mm DETAIL).
(0,2mm is also sifficient, but with 0,1mm has the base 3 layers instead of 2)

Take care the model is very flexible until it glues on the surface.

Model origin

The author marked this model as their own original creation.
