Ender 2 - X Gantry stabilizer

have a Direct Drive mount on my original Ender 2. Got Tired of my X gantry moving every time i pressed the extruder handle to load/unload filament.
Made this to connect between the factory extruder mount and the 2020 profile.

The connecting bolt hole to the 2020 profile are 0.5mm higher than the center of the slot on purpose - to create some positive pressure and keep the gantry level.

M4 screws i believe 25mm... M4 t nuts...

Added a couple of holes on the bottom of this part to screw in a LED holder.

Now I can push on my Gantry and there is no more movement of the profile.

Print Settings

Printer brand:

Creality

Printer:

Ender 2

Rafts:

Yes

Supports:

No

Resolution:

0.24

Infill:

35

Filament brand:

generic

Filament material:

Doesnt matter -

Notes:

5 walls - 34% infill - Make it tough.
