VORON TRIDENT STEPPER DECOUPLER

Reduce VFA, make it smoother, quieter, and more sturdy- get rid of the risk of curving the step shaft due to running at high acceleration for a long time.

ATTENTION: This MOD is made for original A/B drive, not tested for compatibility with other mods, eg Umbilical Mod...

BOM :

2 X D20L30 double diaphragm coupler | https://aliexpi.com/lwOQ

2 Round D Shaft 55x5mm (longer still OK) | https://aliexpi.com/miUU

4 X M3 75mm hex screw | https://aliexpi.com/bF7d

2 x M3 30mm hex screw (use original screws)

4 x M3 6mm hex screw.

4 X 695 2RS bearing | https://aliexpi.com/YE7s

2 X NEMA 17 Stepper Vibration Damper | https://aliexpi.com/2EX7

2 X M3 brass insert nut (OD4.5, 3, 4 or 5mm length is ok) | https://aliexpi.com/Onkg

More details on installation you can follow at this link :

https://github.com/WINTFOX00/TRIDENT-STEPPER-DECOUPLER.git
