XL4015 CC CV buck converter case
Remixed XL4015 CC CV buck converter case from ExtremeExtruder
18
192
1
663
updated October 9, 2024
Description
PDF2024/10/09 update in v3:
- Add ridges to the cap so it won't pop out.
- Enlarge trim-pot holes and merge them together for larger tolerance
- Added label (might be a bit small, but was legible on my printer.)
-----------------------------
Remixed ExtremeExtruder's case from scratch based on his design.
- Lid with holes for adjusting current, voltage as well as openings for screwing input/ output wires
- Make the case smaller because the original from ExtremeExtruder are perfect length-wise but have quite a lot of empty space with the width, at least with the board I have.
- Added 4x2mm holes for fixing the board in place. Need 2mm screw which are quite rare so if you don't have them just skip it.
Tags
Model origin
The author remixed this model. Imported from Thingiverse.
Differences of the remix compared to the original
2024/10/09 update in v3:
- Add ridges to the cap so it won't pop out.
- Enlarge trim-pot holes and merge them together for larger tolerance
- Added label (might be a bit small, but was legible on my printer.)
-----------------------------
Remixed ExtremeExtruder's case from scratch based on his design.
- Lid with holes for adjusting current, voltage as well as openings for screwing input/ output wires
- Make the case smaller because the original from ExtremeExtruder are perfect length-wise but have quite a lot of empty space with the width, at least with the board I have.
- Added 4x2mm holes for fixing the board in place. Need 2mm screw which are quite rare so if you don't have them just skip it.
