Kodak Luma 75 projector mount

With these 3 parts you can mount your Kodak Luma 75 projector upside down on the ceiling. The captive screws allow you to adjust the tilt. The ceiling plate fastens to the ceiling.  First; attach the projector mount to the projector with a ¾ inch ¼-20 bolt. Second; attach the center plate to the projector mount using the captive bolts. Third; attach the ceiling plate to the ceiling. Forth; slide the center plate onto the ceiling plate.

You can modify the design using the included OpenSCAD file. Note: this *.scad OpenSCAD program uses the thread library from https://www.printables.com/model/252225-iso-thread-scad-library.

Print the projector mounting with at least 4 vertical shells and supports. The threads do not need support.
