IKEA SONESAND (and Similar) Hanger Rod Bracket

This is a replacement bracket for the clothes hanger rod bracket that fits onto the inside of various IKEA wardrobes. Dimensions are similar to the original (minus injection molding draft) with an additional M3 hole positioned in the center to provide additional support to the connection if needed. The original part deformed and sheared at the pins due to heavy load on mine which lead to the replacement design.

All dimensions nominal
Pin size: 5 mm
Pin linear distance: 32 mm
Works with rod width: 17 mm

Print instructions

Material: PLA
Fill Density: 50%
Fill Pattern: Rectilinear
Top/Bottom Fill Patter,: Concentric
Perimeters: 4

Requires build plate supports
