SMD magazine for DIN Rail

SMD magazine for mounting on a DIN rail
52
217
3
1177
updated March 21, 2023

Description

PDF

SMD magazine based on the design of robin7331 https://www.thingiverse.com/thing:3952021

Modified base to fit on a DIN rail.

You can change height and gap-width in the user parameters of the Fusion360 file.

Tags



Model origin

The author remixed this model.

SMD Component Magazines
by robin7331 (thingiverse.com)
DIN Rail Clip Basic
by talsit (thingiverse.com)
