Fanatec grip hole pattern template for Formula Rim V1

The plastics on my Fanatec Formula Rim V1  grips started to dissolve. The good news is you can order replacement parts from Fanatec but the bad news is, on the first formula rim these grips where glued, where as the newer ones are easily changeable with a couple of screws. The changeable grips sadly don't fit on the rim because they moved one hole on the rim plate.

I designed a template that you can screw on the rim plate and get the exact spot to drill the hole for the new grips. Simply use some screws and attach the template to the plate.

Info: I am not sure what material the plate is, it looks like aluminium but it is super hard to drill, I strongly recommend a drill press.

print settings:

• 0,2mm layer height
