Curtain rod holder to shutter box

This model is composed of 3 pieces for each side, a center one that holds the rod, with two arms to clamp the shutter box.

You'll need 4 M5 screws & nuts, 2 for each side.

Printed with PLA, 7% cubic infill, 3 perimeters, 6h for each side.

After printing, pierce on the center piece the bridge, in order to place the M5 screw.

Place the nuts on each arm, and screw the center part to the arm, the head on the center part side.

Tighten on the shutter box. Enjoy !

Dimension :

The stl part is for a shutter box that heights 200 mm, and for a 36 mm diameter rod.

The .3mf file is available, feel free to modify it to your specification.
