Mason Jar lid thread source files

Threads for a mason jar lid, built in Fusion 360, fully parametrized, for use in other designs.
43m
1× print file
0.30 mm
0.40 mm
13.00 g
68
533
2
1506
updated February 23, 2023

Description

PDF

Threads for a standard mason jar lid, built in Fusion 360, fully parametrized, for use in other designs. I couldn't find a fusion360 source file to use in other designs, so i built this to share. It's largely based on the thread pitch in the .stl from @loonadrift's Mason Jar Accessories.
Please use and share!
