Hook to be attached to pole, to pull down attic ladder
4
44
0
290
updated February 17, 2023

Description

PDF

This is a hook used to pull down an attic ladder. The hook needs to be fitted to a wooden dowel (22mm diameter, 1 to 2 metres long (that's ~7/8" diameter, 3-6 feet long for Americans)). Its a tight fit, but I also used drilled a hole through the side, and used a small screw to fasten the hook to the pole to be sure.

I printed in PLA with support and 20% infill.  Wall thickness: 1.6mm (4 shells) seems to be strong enough.

Post-Printing
I sanded the hook, undercoated and spray painted with hammer finish paint.

Model origin

The author marked this model as their own original creation.
