Discovery Phaser rotation parts

I fixed the original parts to make them printable also loading then to the site as .stl
19
72
0
413
updated February 17, 2023

Description

PDF

This is a Re-mix of a 3mf file. First part is the emitter. take the emitter pin and fit is into the emitter allowing is to be able to turn freely. then take the emitter washer and fit it over the protruding end of the emitter pin lightly glue the washer to the emitter around the outside edge the inner pin must not be glued as it will no rotate if you do. Glue the main peg onto the the protruding emitter pin then fit the pother parts onto the shaft, gold ring against the emitter, emitter #4 from the original phaser, Silver coin edge washer next then the emitter #6 from the original phaser model.
