“Helical Hearts” twist apart into two separate but identical pieces.
154
1177
18
4718
updated February 17, 2023

Description

PDF

This was made by DaveMakesStuff.  I found it and think it would do great here. I did nothing to this item but am unable to find something like it here.

These “Helical Hearts” twist apart into two separate but identical pieces. Print in different colours to highlight the spiral curves.

The “Large Helical Heart” has a hidden compartment for rings or contraband.

See here for video: https://youtu.be/SSzDglASqT4

See here for stable downloads:
Large (plain and with hidden compartment): https://social.thangs.com/m/690383
Small: https://social.thangs.com/m/690164

The “Large Helical Heart” is 80mm at the widest point, the “Small Helical Heart” is 50mm at the widest point.

In order to preserve a smooth sliding contact surface, print the files on the side as they are oriented. Try raising the model off the bed by 3mm or so and building tree support up to the overhangs.
