Blank XDA profile Keycaps

Two different versions of XDA keycaps, modeled with FDM printing in mind. They are compatible with Cherry MX switches.

Since we couldn't find any official documentation of the XDA profile, we made two different versions of the model, matching what we see from commercial keycaps. There is a more rounded version and a squared version.

You can choose any of the two as you prefer :)

Both have a flat top, so you can print them upside down, and add any logo, or custom image on the first layer.

Print instructions:

Print at low speed, and 0.15 mm layer height or lower for best results.

We only tried using a 0.4 mm nozzle, and PLA filament. We got better results when printing on the colder end of the temperature range for the filaments we used.

Depending on your filament, you may need to scale up or down slightly on the XY plane to adjust the clearance for inserting the switches. The published models have the dimensions that worked for us.

Happy printing!
