Ender 3 S1 Pro X bar mount for dial / digital indicator

A simple clamp to hold a dial or digital indicator gage on the X axis bar for precise bed leveling.
22
143
1
929
updated February 9, 2023

Description

PDF

I suspect there are better models available, but I really enjoy the design process so I almost always design my own accessories. This model requires two M4x35mm bolts and nuts. I use an old soldering iron to secure the plugs.

The knobs are an early, but acceptable to me, attempt at knurling.

I hope it works as well for you as it does for me. I'm planning on another model that will allow easier rotation (this model requires removing the bolt to change the indicator's orientation).

Thanks for looking.
