Parametric Circular Device Mount

I created this model to mount my TP-Link Deco M5 mesh wifi.  I wasn't able to find any existing circular mounts that would fit the M5.  This mount is fully customizable and parameterized via OpenSCAD.  It can be printed with either a built in mounting pin or with a screw hole for mounting.

The provided STL should be the proper size to mount a Deco M5.

If you customize the scad file here are a few tips.

• DeviceWidth is the the diameter of object.
• I would recommend a wall thickness of at least 4 for most applications.
• If you do not wish to have a hole for cables then set CableHoleWidth to 0.
• To generate a screw hole and not a pin set PinLength to 0 and set the screw parameters.

If you use the built-in pin version, I recommend you use 80% or higher infill otherwise the pin may break off when removing from the honeycomb wall.

2024-02-22 - v3: Added a ChopBottom property to completely chop the bottom off below a certain point rather than create a cable hole.  ChopBottom = 10 would chop 10mm below the center of the mount hole or 10mm below the bottom of the pin.

Adapted parametec flashlight holder to hold disc shaped objects on their side.
