Opening angle stop for Blum Aventos HF system

This angle-stop is for the Blum Aventos HF which is a bi-fold cabinet door system.

These files provide models to be used in place of any Blum 20F70x1 stopper (such as 20F7011 or 20F7051) but allows your to use any angle instead of the stock 83° and 104° provided by Blum.

Personally I had to set it to 60° to avoid hitting another door.

Usage

1. Open the included source blum-aventos-hf-opening-angle-stop.FCStd file with FreeCAD (a free and open source 3D modelling software)
2. From the model tree, double-click on the Spreadsheet object.
3. Modify the B1 cell to the angle value of your choosing.
4. Single-click on the Body object from the model tree.
5. Select File → Export... (or Ctrl + E) and select the output STL file destination.
6. Slice the outputted STL file using 100% infill with your favourite slicer.
7. Print.
8. Install using the same method used for stock 20F70x1 stoppers. Instructions can be found on Blum's assembly resources.
