Diaton Roma F4LR DJI O3 holder + TBS nano RX holder

3D model to mount you DJI O3 air unit to a Diaton Roma F4 Long Range model. T
1
16
0
251
updated March 19, 2023

Description

PDF

The O3 air unit holder includes the space for mounting the O3 air unit and antenna obviously ;) , but it has place for a TBS Immortal T antena and BN-220 GPS unit. Additionally i supplied a holder to mount the TBS Nano RX on the bottom of the drone frame. The antenna and GPS are fixed in place with a zip tie.

I printed the mode with TPU 98A with nozzle diameter 0,4mm and layer height 0,2.



UPDATE:

  • DJI O3 holder has been update to reposition the TBS immortal T antenna to a better position
  • added holder for beeper on the bottom of the drone.
