Anet A8 X-belt tensioner for GT2 pulley

I printed the Anet A8 improved X-belt tensioner by freemark and needed to customize it a bit as I wanted to use a toothed pulley instead of the stock one.

Furthermore I felt as there was a size mismatch for the nut. I would have needed a M4 to fit but an M3 screw.

This was designed for a GT2 16 or 20 tooth pulley combined with M3 washers on either side.

For installation instructions read the files supplied by with freemark's thing.

A big thank you to mtepedino who provided measures and help in testing the 20 tooth prototypes.

Print Settings

Printer:

Anet A8

Rafts:

No

Supports:

No

Resolution:

0.2

Infill:

20%

How I Designed This

Printed the original thing and took measures from that plus from the pulley I had already bought.
