Solder Fume Extractor (120mm Fan 12V)

SOLDERING FUME EXTRACTOR (Ver 1)

Easy print no supports required to house a 120mm 12v fan.

Parts
Front Fan Housing
Back Fan Housing
Filter Housing (2 Parts)
Tray with 8mm circular hole and 15x8mm rectangular hole
Tray (Blank No Cut Outs) (Optional)

Hardware required
4 off M4x6 screws
Carbon Filter Mesh (Cut to Size)

Future plans (Maybe)
Lighting
Flexi Arms to Hold parts
Volt/power display
AUX USB port on front

Works up to 10cm away any further just causes turbulence in the fumes.

Drill the holes you need in the tray or edit as required depending on your power source and switches. I made a 12v 3s2p 18650 DIY pack with a balance lead charging point
