Omnifixo - Field box (alternative v2)

A remixed version of the original OMNIFIXO field box that fits a few more items and an ajustable soldering iron stand
46
101
2
3821
updated January 26, 2023

Description

PDF

This is a remixed version of the original OMNIFIXO field box that can be found here: https://www.thingiverse.com/thing:5436769

I have edited the internal layout to fit a few more items and also redesigned the soldering stand to allow for a removable, adjustable angle version that uses a bit of scrap aluminium tube (10mm ⌀ dia x 52mm length).

The soldering stand slots into place from above, then you set the angle and push/clip it further into the box to keep it in place. You will hear a clicking when you set to another angle.

This box holds the following:

  • Omnifixo Third Hand (logo/ruler face up or face down)
  • TS80 Soldering iron
  • a bit of solder
  • wire tip cleaner
  • a spare soldering iron tip

Parts needed to build:

  • ASA/ABS filament
  • Qty x 4 off 6mm dia x 3mm magnets
  • Aluminium tube 10mm dia x 1mm wall x 52mm length

This was printed on the Prusa and to prevent warping I added glue and extended the brim to 10mm. I also changed 'Print settings > Skirt and Brim > Skirt > Draft shield > Limited

Some images show this field box next to my Olfa AK-4 & spare blade box.

Category: Tool Holders & Boxes

Tags



Model origin

The author remixed this model. Imported from Thingiverse.

Omnifixo - Field box
by OMNIFIXO (thingiverse.com)
