Added front label to Parametric hinged small parts box

Added front label to box so if its on the bottom of a stack I can find the right box
27
131
0
1315
updated January 27, 2023

Description

PDF

This is a small change to Billiam's latching/hinged parametric box, built in CascadeStudio.  To use, download the box.txt file to your computer and change the extension to .json.  Install Cascade Studio.  Start CascadeStudio, click on "Load Project" and open box.json.  The only change will be an additional check box for “Show label on front?”.

For the screw boxes included here I put several spaces in front of the text to move it away from the latch, this would not be needed for a taller box.

This is a very minor remix, so all credit goes to Billiam for developing this very nice design and giving me an opportunity to learn about CascadeStudio.

Model origin

The user re-uploaded this model. The user is not the original author of the model.

Parametric hinged small parts box
by Billiam
