VR Stock Gun for Oculus/Vive - Very easy and cheap

Another VR Gun stock for Onward, Pavlov, BAM, Battle Royal…

Parts you will need:

• One inch wooden stick or PVC tube (approx 45cm is fine, but you can adapt it to suit your preferences)
• 2 x M4x20mm screws + 2 M4 Locknuts
• 2 x M3x16mm screws + 2 M3 nuts for adapting the stock to the stick (optional as you can also use the simple adapter and glue it)

You need to print:

• 2 x Support Mount (provided)
• 2 x Screw (provided)
• 1 x any adapter (provided)
• 1 x stock (provided)
• 2 x Mount for Oculus Touch or HTC Vive (Not provided but there are plenty.)

Here is the Oculus Touch Mount I used: https://www.thingiverse.com/thing:2403797/#files. Simply mirror it on your slicer to have the right mount.

The photo shows an early prototype with a different stock that I had to adapt (From https://www.thingiverse.com/thing:2057419, all credits to Gurgelx). My stock is slightly bigger, require less support and fits a 1-inch stick.

You will need to glue the screws into the plastic nuts and to glue the Mount to the supports. I am testing so magnets for make it easier to load, I will adapt the file if my tests are positives

I can modify the files to any diameter, feel free to ask

!!! ------ Note that I can print it for you and send a full kit including screws and stick! ------ !!!

Order a full kit here :)

Credits: Gurgelx for the stock in the photo and for the Oculus touch Mount

It takes me a lot of time to design these parts from scratch. Please help me develop new parts and release them for free / pay me a beer to say thanks on http://paypal.me/supportp3x

Print Settings

Printer Brand:

Prusa

Printer:

i3 MK2S

Rafts:

Doesn't Matter

Supports:

Yes

Resolution:

.300

Infill:

20%

Notes:

I used PLA, with a BRIM for the supports
