Desktop Case for 800x480 5" Touchscreen

I got a 800x480 5" Touchscreen as additional interface for my octoprint raspberry. Also I wanted the option to use it as a always on monitor for a CCTV.

This is a simple stand, printable without supports. I used M3 nut inserts by ruthex to screw the parts together. There are two throughholes for a cable tie and an indent for a magnet, to secure cables and make it stick to a metallic surface.

The Display is mounted upside down, so the output of the raspberry has to be turned by 180°.

Parts needed:

• 6 M3 nut inserts (or make the holes a bit smaller so that you can screw directly into the plastic)
• 90° HDMI plug male/female
• 2x 90° MicroUSB for power and touch interface

The stand angle and almost all sizes are easy changeable. I'm just a beginner, but I think I created all measurements in dependence of the dummy-PCB-body inside fusion, so changing the PCB sketch should change all other measurements.

Print Settings

Printer Brand:

Prusa

Printer:

I3 MK3S

Rafts:

No

Supports:

No

Resolution:

0.2

Infill:

15

Filament: Nunus ABS Pink

Notes:

This is an easy print und should work fine on almost all printers.
I printed the bezel face down and flat, the backplate with the outer shell on the bed and flat. The stand is printed on its side.
