Simple Strong Headset Wall Mount

I have designed a simple, but yet strong headset wall mount. Dimensions are 90mm length, 30mm width, 43mm depth, 8mm in thickness, & mounting holes are 4mm.

Note to content creators (YouTube, Patreon, Educators, etc). Yes I understate that you are "technically" getting paid in the backend for creating content & thank you for creating that content. So to expand everyone's knowledge, you have permission to use this design in your content as long as you: State that it is not yours & acknowledge who designed it. Provide a link to where you got it from, so others can download & enjoy it as well.

BTW if you like my design, please don't forget the click the "like" button & show you appreciation.

Thanks & Enjoy!

Print Settings

Printer Brand:

TEVO

Printer:

Tornado

Rafts:

No

Supports:

No

Resolution:

.20

Infill:

20% or higher

Filament: Your Choice PLA or PLA+ Your Choice

Notes:

I printed it on a glass build sheet using binder clips to hold onto the ceramic glass bed that the Tevo Tornado has & applied a glue stick to the glass build sheet, so that the print can adhere to. Using Sunlu PLA+ black filament the initial bed temp was 70C, nozzle temp 215, no cooling fan, & print slow on the first layer (I had it at 25). On the 2nd layer to finish drop to bed temp 60C, nozzle temp 215, cooling fan high, & increase print speed back to normal. Note: I did use a skirt to prime the nozzle, but is it your choice.
