Ender 3 Direct Drive BTT Smart Filament Sensor Mount

*For Creality Ender 3/Pro/V2 Printers Converted to Direct Drive Only*

Converted my Ender 3 V2 to direct drive and needed a place to mount my BigTreeTech (BTT) Smart Filament Sensor. The mounts I found were located in a place that would restrict the direct drive movement, were not secure, or were mounted on the X-gantry (wanted side mount as my filament dryer sits beside my printer). This mount replaces the back panel of the filament sensor and mounts securely in the stock extruder location.

Hardware needed:

-(4) M3x8mm screws (I used socket head, but I recommend button head for clearance)

-(4) M3 nuts

Print Settings

Printer Brand:

Creality

Printer:

Ender 3

Rafts:

No

Supports:

Yes

Resolution:

0.2

Infill:

100

Filament: Duramic PLA+ Electric Blue

Notes:

Print settings and filament are what I used. Feel free to use what works best for your printer.
