VFR800 Oil Funnel M24x3 Thread

This is a 2 piece part as the nut spins on the funnel
13
168
0
1044
updated January 12, 2023

Description

PDF

I find the angle a bit annoying as my normal oil funnel falls out if not held in. I hadn't modeled or printed a thread  so I thought I'd make this.
I made this for my RC46 VFR800 but it will probably work on many bikes with an M24x3 thread as the nut spins on the funnel.
