Cable sorter - Cable organizer

This is a parametric model of a cable organizer that is screwed to the wall. Designed to be printed without support.
77
512
9
2333
updated January 7, 2023

Description

PDF

Versions

Two models with 200mm and 150mm length of the back-panel of the organizer were uploaded as .stl together with the freecad-file. The exact parameters for the two variants are listed in the attached screenshots.

It is possible to have two different distances on each half of the organizer (please see the attached screenshots).

Printing

Two different parts were printed in Prusa-PETG with 30% infill and 0.15mm layer height on a Prusa-MINI without support (parameters see pictures and screenshots). The distance between the fingers is ~8mm on one side and ~6mm on the other side of the organizer. The results are shown in the attached pictures.

Modifications

By changing the appropriate values in the spreadsheet in the file, one can change the length of the back-panel of the organizer, the length and width of the single fingers and the number of fingers.

The model is made in FreeCAD. To avoid any toponaming issues during updating use the current version of realthunder branch.
