PC4-M10 PTFE Tube Pneumatic Fitting Model (Not for Printing)

Excellent model for designing parts with these fittings.

Perfect! I just needed this model for the CAD rendering of the PC4-M10 PTFE Tube Pneumatic Fitting Wrench that I'm about to publish. Thank you so much for making it available on Printables!

Thanks for sharing, it was useful when I need this for my model.

Note for others: the M10 thread pitch in this model is 0.75, while I found most of the actual M10 fittings - at least what I have - have 0.9 pitch.

Thank you very much for this model. Very useful for designing.

great! used it to make my ptfe adapter.

Great model for illustration and CAD assembly purposes. Used it in several assemblies and in the documentation of my models. It's been very useful.

Even though the thread is great, it doesn't hold the PTFE-tube in place.

It is great for testing purposes.

Printed with 0.4, PETG with 0.1mm layer height.

Printed this to use with filament guide, unfortunately the thread didn't really turn out great. Used a coupler from a spare hotend in the end. Still nice to have this model as a reference though.
Cheers
