I really recommend printing this gearbox, it is really quiet and easy to assemble. If you're looking for a good gearbox, this is a very good option.

14

Zeger

@Zeger_2003899

Really cool and good design, thanks, there is Just a little bit more space between te gears and the walls then i would like, zo i have resulted in using 9 gears (edited)

8

D. Bos

@DBos_1897611

Changed nothing to the model and works really perfect. I'm curious what the ratio of this gearbox is

4

jonjon

@jonjon_519461

@DBos_1897611 The overall gear ratio is dependent upon the individual gear ratio of each mesh and the total number of meshes. Since all the gears are identical, each mesh has a gear ratio of 4:1 (60 tooth gear meshed with 15 tooth gear).

With 7 gears, as you have printed, there are 6 meshes. Therefore, the overall gear ratio is 4^6:1, or 4096:1.

P 1

Pro Gamer

@ProGamer_1098231

TO BIG RODS MAKE THEM SMALLER

7

Sahan

@SahanRohanat_1001872

10

Yeray Martinez

@yerolopolo_828206

22

JanisMi

@Janis

Might have missed something in the description, but gear center could print a bit smoother. Cool design anyway

12

Joseph Newburg

@JosephNewburg_519123

Printed easily. Used PETG for the rods and gears. PLA for the housing to make the supports easier to remove. Agree with the other commentator that a little more height in the housing would prevent the gears from rubbing against it at speed.

Edit: Without any oil or anything this thing runs smoothly and relatively quietly. (edited)
