Replacement hinge for RAISE3D E2
RAISE3D E2 top panel hinge with 270 degree articulation. 45mm in length, 25mm hole spacing. 4mm diameter holes.
5
29
0
168
updated March 27, 2023
Description
PDFHinge designed as replacement for RAISE3D E2 top lid. 0.25mm tolerances. Printed laying down in PLA without supports, supports could be added for more accurate hole recess.
Can also be used for other applications
Tags
Model origin
The author marked this model as their own original creation.
