Accelerometer Mount for ADXL345 on Ender-3 S1 Pro
Mount for an ADXL345 3-Axis on an Ender-3 S1 Pro with stock sprite fan configuration.
28
440
3
3267
updated January 3, 2023
Description
PDFModeled for Ender-3 S1 Pro using right-hand stock fan mounts. Reuses stock short M3 from shroud to mount the sensor, mated with a M3 x 4mm brass insert. Requires M3 x 8mm, possibly 6mm, to replace the repurposed shroud screws.
Amazon US link for the sensor
Diitao GY-291 ADXL345: https://a.co/9movHVn
Printed at 30% honeycomb infill in PETG. Designed on Fusion360.
