Haribo 3030 X-axis with belt tensioner and cutouts for couplers

This is the remix of the original x-axis from Prusa with additional belt tensioner. If you have Haribo and original Prusa motors (with integrated rod), it works fine, but when you have steppers and Z threaded rods connected using couplers, it's not possible to lower the Z axis enough to reach the bed. One solution is to raise the bed by couple of mm, my solution is to modify x-axis motor mount and idler with cutouts for couplers.

The original files were modified by extending the width of part by 2.5 mm, moving x-axis endstop and shorting bearing holders on x-axis to acomodate couplers. Max coupler diameter is 25mm.

The source files are available on Github

Print Settings

Printer:

Haribo

Rafts:

No

Supports:

No

Resolution:

0.2mm

Infill:

20%

Notes:

PETG
