Yet another V-Minion electronics box

Built in electronics box
48
254
4
1617
updated January 4, 2023

Description

PDF

This is remix of another great remix created by Dan Cernogorsky.

List of changes:

  1. Added original RR electronics box cable clamp for wires management
  2. Re-oriented control boards to fix collision of SKR2 driver heatsink with Raspberry Pi
  3. Modified back support making it to rest against the extrusion
  4. Added sacrificed layer in screw holes to support overhangs
  5. Added some zip ties connection points for wires management
  6. Added standoffs for optional LM2596 for those who wants to use single Noctua-4x10 silent fan
  7. Modified the lid for single fan option (both lids are included for your choice)

Supported boards:

SKR2

SKR E3 mini v2/v3

SKR Pico

Pico board might need spacers which are included. Other boards don't need spacers standoffs are leveled to provide enough clearance for bottom pins.

Model origin

The author remixed this model.
