Lenticular Dishwasher Clean/Dirty Sign (Customizable)

V1 designed to have magnet (http://a.co/1zNqvzm) added and glued in after printing.

V2 designed to have magnet (http://a.co/1zNqvzm) inserted approximately 2.65mm into the print (Z). Pause your print before it starts printing the layer immediately above the magnet, insert the magnet, and resume printing.

You can also now use Customizer to add a custom magnet size, select whether you want the magnet embedded (like V2) or not, and change the thickness of the first two layers of your print.

It helps if you color in the cutouts for the lettering with permanent marker to make the text more visible.

Also included the text that is cut out for those with dual extruders. I have not tested this as I only have a single extruder.

17Oct2017: Added separate text that is cut out for clean and dirty for those with 3+ extruders/MMU.

Video: https://youtu.be/0RumCvPu-A4

Inspired by http://bit.ly/2xsDEkv

Print Settings

Rafts:

Doesn't Matter

Supports:

No

Resolution:

0.2mm

Notes:

V2 magnet insert is designed for first layer height of 0.35mm and other layers of 0.2mm.
