FuzNuz Bridle Rack

New FuzNuz design out, this one is a completely new design for a standard sized bridle rack. Key features include: A…
14
124
0
671
updated December 17, 2022

Description

PDF

New FuzNuz design out, this one is a completely new design for a standard sized bridle rack.

Key features include:

A strong dip shaped design to hold all sizes of bridles securely on the rack.

Four holes for size #8 wood screws with countersinks for a secure flush mounting on wood.

Can also be bolted to magnets for trailer applications.

A holding peg for carrying light items. It is recommended to not place any object weighing over 3 lbs (1.5 kg) on the holding peg.

A name plate for a label that measures 1.5 inches by 0.25 inches.

4 inch diameter compact size to fit in most installations.

Rapid print time, mine took 3 hours to print at 0.4 mm layer height and 15% fill density, At higher fill densities it may be stronger, but the 15% already is sturdier than our metal bridle racks.

No support material is required. Meaning no clean up or polishing, just print and mount.

Here is a quick guide of links to my other FuzNuz horse equipment items:

FuzNuz Horse Curry Comb: https://www.thingiverse.com/thing:2895714

FuzNuz Hoof Pick: https://www.thingiverse.com/thing:2895718

FuzNuz Horse Hoof Rasp Handle: https://www.thingiverse.com/thing:2894276

FuzNuz Bridle Rack: https://www.thingiverse.com/thing:2906951

FuzNuz Salt Block Holder: https://www.thingiverse.com/thing:2915903

FuzNuz Horse Pocket Sweat Scraper: https://www.thingiverse.com/thing:2932018

FuzNuz Modular Scratching Plate: https://www.thingiverse.com/thing:2942174

Category: Pets
