Honda CM185T speedo gasket

Goes between the plastic speedometer assembly and the aluminum holder-piece that it sits in.
4
21
1
269
updated December 16, 2022

Description

PDF

This replaces the foam gasket thing that goes between your plastic speedometer and the part of the handlebar clamp that it sits in.
Since it's been ~40 years and actual Honda part has been out of production for a while now, but to be honest I couldn't even find a part number for this at Ronayers.com or anywhere else. This may work for a CM200 as well, as long as it has the same speedo.

In any case, this will only really work if you use flexible filament (TPU). I am not amazing at cad, and this speedo has subtle curves and tapers to it, even though it just looks like a rectangle with rounded corners.
I guess you could print it in PLA and just dip it in hot water before fitting it onto the speedo. This would be more of a spacer than a gasket, but it would at least keep your speedo from rattling around.

Print settings:

  • tpu
  • .3 layer height
  • no support
  • avoid crossing perimeters
