Empanadilla Maker

This is a simple Empanadilla Maker (turnover maker). Empanadillas, also known in Puerto Rico as empanadas or pastelillos, are baked or fried pastries. Here in Puerto Rico we eat them stuffed with a lot of things, like meat, chicken, pizza sauce and cheese, guava paste, shrimp... you name it. The are really good! This little device is used to fold the empanadilla and close the seam. Since the PLA I used may not be the safest, I use the same paper that separates the pastry to fold them, avoiding the food from touching the plastic. Just in case... That also keeps it clean.

You will ned two 5mm screws for the hinge. You may want to print some plastic screws for this. The hinge does not take too much load.

Print instructions

Category: Kitchen & Dining Summary

This is a simple Empanadilla Maker (turnover maker). Empanadillas, also known in Puerto Rico as empanadas or pastelillos, are baked or fried pastries. Here in Puerto Rico we eat them stuffed with a lot of things, like meat, chicken, pizza sauce and cheese, guava paste, shrimp... you name it. The are really good! This little device is used to fold the empanadilla and close the seam. Since the PLA I used may not be the safest, I use the same paper that separates the pastry to fold them, avoiding the food from touching the plastic. Just in case... That also keeps it clean.

You will ned two 5mm screws for the hinge. You may want to print some plastic screws for this. The hinge does not take too much load.

Print Settings

Printer Brand: Prusa

Printer: Prusa Steel

Rafts: No

Supports: Yes

Resolution: 0.2

Infill: 50%

Notes:

I sliced this in Simplify3D using two processes. The first one prints at 0.2 resolution and 50% infill (I wanted this to be strong) from Z = 0 to 12.26 mm, using no support. The second one has the same settings but using support. This is in order to avoid putting support on the letters at the bottom of one of the parts, but add support at the hinge holes.

How I Designed This

Designed in Autodesk Inventor

I used Autodesk Inventor to create this model based on the dimensions of this thing (http://www.thingiverse.com/thing:850772). The parametric model is included in the zip file.
