Keter Glenwood pillowbox bottom stabilizer

Wanted to have some support in the middle under the bottom plate, so it doesnt bent to much over time.
1
7
0
131
updated December 15, 2022

Description

PDF

english below

Ich dacht mir, dass sich der Boden von der Kissenbox bei etwas mehr Belastung schnell verformen könnte. also habe ich ein paar Stützfüße konstruiert, die stabil und ziemlich Luftdurchlässig sind, um dem Holz darunter Luft zum atmen zu lassen.
Die Füße sind praktisch genauso hoch wie die Beinchen an den Ecken von der Kiste.
Maße sind quadratisch 150mm verjüngend zu 100mm bei einer Höhe von 20mm
Ich empfehle den Umwelteinflüssen halber PETG oder ASA/ABS.

I thought that the floor of the cushion box could deform quickly with a little more load.
So I constructed some support that are stable and fairly permeable to air to allow the wood underneath to breathe. The feet are practically as high as the legs at the corners of the box.
Dimensions are square 150mm tapering to 100mm at a height of 20mm.
I recommend PETG or ASA/ABS for environmental reasons.
