A case I designed for my HomeAutomation server based on Raspberry Pi 3B.

The case is for:

The stl files are without any logos (seen on photos).

tiffany-power-plug.stl is only to close power-line of x820 (storage-board). I cover the plug to avoid any mistakes when connecting power-line (which is only 5v-tolerant, while I'm using 12v line by powering through x735).

tiffany-usb-bridge-cover.stl - just to cover ugly usb-bridge. Not really necessary, but makes view a bit 'nicer', and less chances to get some short.
