Plumb Bob Spool

I designed this to fit a Swanson hexagonal plumb bob. The inside edge of the opening has a small lip, so when the plumb bob goes in, it goes in snug. Once it's past the lip though, it's looser (though it doesn't rattle) and is easy to pull back out. The end of this bob has a metal ring used for hanging the plum bob. The end of this spool has a couple of pegs for that ring to attach to, to keep the spool from unspooling.

The magnet channel can hold five small magnets. It was designed for these: https://www.amazon.com/gp/product/B01N2AU7X3/ref=as_li_ss_tl?ie=UTF8&psc=1&linkCode=sl1&tag=persofinanfir-20&linkId=f18f9058931a0b20a783567a2592156f

The magnet dimensions are: 2mm tall with 6mm in diameter

Even the strongest magnet of that size won't allow the plumb bob to just hang from the spool when it's attached to something magnetically, because the bob itself is quite heavy. The magnets have other uses, but you don'thave to add them.

Timelapse: https://youtu.be/ICP228KTF9k

This thing was made with Tinkercad. Edit it online https://www.tinkercad.com/things/gJQLcX0AxEs

Print Settings

Printer Brand:

Wanhao

Printer:

Wanhao Duplicator i3 V2

Rafts:

Doesn't Matter

Supports:

Yes

Resolution:

.3

Infill:

15

Notes:

It needs supports everywhere so inside the bob channel doesn't collapse. The print resolution can be rough, it's for a tool, not a fashion show. The one pictured was printed at .2, with 20% infill, in clear PLA (to see the magnet channel).rnrnTo clear the support material in the internal bob channel, I used a scratch awl type tool. Long, pointy, and strong. A wood chisel would probably work great too. It doesn't have to be perfectly clean.

Category: Tool Holders & Boxes
