ZIMABoard with SATA and PCIe Cards

This is a crude modification of two Printables.com projects.
14
111
1
1650
updated April 11, 2023

Description

PDF

This is a crude modification of two Printables.com projects:

- ZimaBoard Wall Mount w/SSD:
https://www.printables.com/model/178994-zimaboard-wall-mount-wssd
And
- ZimaBoard Wall Mount for Generic PCIe cards:
https://www.printables.com/model/215289-zimaboard-wall-mount-for-generic-pcie-cards

Specifically so that I could use the existing ZIMABoard Plates with a SATA SSD Installed and also raised enough to have the PCIe Board connect with support.
