Ender 5 Linear Rails Mod (Updated: 2021/12/03)

Update Dec. 3, 2021:

New design upload was long overdue. Almost all of the parts have received a revision. This will give you full build plate use and works extremely well!

These are all of the printed components to mod the Ender 5 to use linear rails. I made this as minimalist as possible in order to not need to buy a lot of extra components and to avoid extra flex.

Hardware:

• 3 x 300mm Linear Rails with MGN12H Block
• 6 x GT2 Idler Pulley 20 Teeth 5mm Bore
• 36-ish x M3 Slide in T Nuts OR M3 Hammer Head T Nuts
• 42-ish x M3x8mm Screws
• 6 x M5x20mm Screws
• 2 x M4x35mm Screws

Please see my video series on this mod:

Part 1: https://youtu.be/tf8bVFscOOM

Part 2: https://youtu.be/zYssU7fBEEk

Part 3: https://youtu.be/tO1P2wx0L1Y

Latest Update: https://youtu.be/YVEKWypxyGo

(Amazon Links are Affiliate Links)

Print Settings

Printer Brand:

Creality

Printer:

Ender 5

Rafts:

No

Supports:

No

Resolution:

.2mm

Infill:

50%

Filament: Any HTPLA
