Genmitsu DIY CNC 3018 Crossbrace - Rigidity upgrade -
Bracing to add rigidity to the X axis between the 2020 profiles, i had a feeling there is some torsion annoying torsion
17
88
0
710
updated November 6, 2022
Description
PDFsuper rigid upgrade that holds the 2020 alu profiles together to minimize flex, i printed them in PETG and they are definitely rigid
The Machine isn't flimsy, but well, every little bit helps to be able to push the machine
You might need to loosen or remove one of the aluminum profiles to add the bracing, at least if you want to add the hammernuts beforehand.
