TS-520 Band select switch rod connector

This is a repair part to fix the rod connector for the band select switch inside the TS-520.
In the contest Repairs
4
9
1
98
updated October 15, 2022

Description

PDF

This is a repair part to fix the rod connector for the band selector switch inside the TS-520 transceiver. You can read about the repair on my blog:

https://alaskalinuxuser3.ddns.net/2020/11/09/fixing-a-ts-520-band-select-switch/



This part is no longer manufactured by Kenwood, so I made this 3D part to fix it. The zip file is the cad files I used to create it. If you slice the stl, be sure to make it stronger by 100% infill.

Model origin

The author hasn't provided the model origin yet.
