Radial/rotary engine toy (print in place)

5 cylinder engine with a hole for a 4 mm Allen wrench in the crankshaft
2h 13m
1× print file
0.20 mm
0.40 mm
27.00 g
In the contest Mechanical Marvels
119
517
7
2416
updated November 17, 2024

Description

PDF

This model can show both a radial engine (rotating crankshaft with a stationary body)

and a rotary engine (stationary crankshaft with a rotating body).
