Sensor Holders for 4040 T-Slot Plate (18mm & 30mm)

These sensor mounts were primarily made for the FANUC Standard educational package, so that additional sensors could be installed, but will work with anything that uses the 4040 T-slot plate system.

The holders can be installed both ways horizontally, so with both in the same T-slot rail or in two neighboring ones.

I tried to make them as easy to print as possible, so no supports are needed, and as low-profile as possible, for the robot to be able to navigate between them easier.

T-Nuts are required, but are easy to 3D print if needed.

Blender source files are also included, with the cutting done via boolean modifiers.

For the other Fanuc parts that are visible on the picture, visit https://www.thingiverse.com/thing:5413451

Made for BSZC Nemes Tihamér High-School on request

Print Settings

Printer Brand:

Creality

Printer:

Ender 5

Rafts:

Doesn't Matter

Supports:

No

Resolution:

0.12 for added stability

Infill:

95+%

Filament: Prusament PETG Grey
