Arducam 5MP Wide Angle USB Camera Mount - UB0233

Arducam 5MP Wide Angle USB Camera Mount - UB0233
22
204
3
1268
updated September 22, 2022

Description

PDF

I bought this Arducam 5MP Wide Angle USB UB0233 camera on Amazon, to try out with OctoPrint.  I had it wired up with twist ties.  I couldn't find a mount specific for it, so I figured I'd make one.

There's a Logitech C270 style connector and an action style connector.  Depending on the style you use.  You can use a few m3 screws and nuts as spacers to hold it on the mounts.  The enclosure printed pretty well that the cover just fits right on.

Only supports I used, were an itty bitty amount under the enclosure connector, but in other tests it still looked ok.
